词条 | Compressed air car |
释义 |
A compressed air car is a compressed air vehicle that uses a motor powered by compressed air. The car can be powered solely by air, or combined (as in a hybrid electric vehicle) with gasoline, diesel, ethanol, or an electric plant with regenerative braking. TechEngines{{Main|Compressed air engine}}Compressed air cars are powered by motors driven by compressed air, which is stored in a tank at high pressure such as 31 MPa (4500 psi or 310 bar). Rather than driving engine pistons with an ignited fuel-air mixture, compressed air cars use the expansion of compressed air, in a similar manner to the expansion of steam in a steam engine. There have been prototype cars since the 1920s, with compressed air used in torpedo propulsion. Storage tanks{{Main|Compressed air tank}}In contrast to hydrogen's issues of damage and danger involved in high-impact crashes, air, on its own, is non-flammable, it was reported on Seven Network's Beyond Tomorrow that on its own carbon-fiber is brittle and can split under sufficient stress, but creates no shrapnel when it does so. Carbon-fiber tanks safely hold air at a pressure somewhere around 4500 psi, making them comparable to steel tanks. The cars are designed to be filled up at a high-pressure pump. In compressed air vehicles tank designs tend to be isothermal; a heat exchanger of some kind is used to maintain the temperature (and pressure) of the tank as the air is extracted. Energy densityCompressed air has relatively low energy density. Air at 30 MPa (4,500 psi) contains about 50 Wh of energy per liter (and normally weighs 372 g per liter).{{citation needed|date=March 2017}} For comparison, a lead–acid battery contains 60-75 Wh/l. A lithium-ion battery contains about 250-620 Wh/l. The EPA estimates the energy density of gasoline at 8,890 Wh/l;[1] however, a typical gasoline engine with 18% efficiency can only recover the equivalent of 1694 Wh/l. The energy density of a compressed air system can be more than doubled if the air is heated prior to expansion. In order to increase energy density, some systems may use gases that can be liquified or solidified. "CO2 offers far greater compressibility than air when it transitions from gaseous to supercritical form."[2] EmissionsCompressed air cars could be emission-free at the exhaust. Since a compressed air car's source of energy is usually electricity, its total environmental impact depends on how clean the source of this electricity is. However, most air cars have petrol engines for different tasks. The emission can be compared to half of the amount of carbon dioxide produced by a Toyota Prius (being around 0.34 pounds per mile). Some engines can be fuelled otherwise considering different regions can have very different sources of power, ranging from high-emission power sources such as coal to zero-emission power sources. A given region can also change its electrical power sources over time, thereby improving or worsening total emissions. However, a 2009 study showed that even with very optimistic assumptions, air storage of energy is less efficient than chemical (battery) storage.[3] AdvantagesThe principal advantages of an air powered engine is
DisadvantagesThe principal disadvantages are the steps of energy conversion and transmission, because each inherently has loss. For combustion engine cars, the energy is lost when chemical energy in fossil fuels is converted by the engine to mechanical energy. For electric cars, a power plant's electricity (from whatever source) is transmitted to the car's batteries, which then transmits the electricity to the car's motor, which converts it to mechanical energy. For compressed-air cars, the power plant's electricity is transmitted to a compressor, which mechanically compresses the air into the car's tank. The car's engine then converts the compressed air to mechanical energy. Additional concerns:
Crash safetySafety claims for light weight vehicle air tanks in severe collisions have not been verified. North American crash testing has not yet been conducted, and skeptics question the ability of an ultralight vehicle assembled with adhesives to produce acceptable crash safety results. Shiva Vencat, vice president of MDI and CEO of Zero Pollution Motors, claims the vehicle would pass crash testing and meet U.S. safety standards. He insists that the millions of dollars invested in the AirCar would not be in vain. To date, there has never been a lightweight, 100-plus mpg car which passed North American crash testing. Technological advances may soon make this possible, but the AirCar has yet to prove itself, and collision safety questions remain.[14] The key to achieving an acceptable range with an air car is reducing the power required to drive the car, so far as is practical. This pushes the design towards minimizing weight. According to a report by the U.S. Government's National Highway Traffic Safety Administration, among 10 different classes of passenger vehicles, "very small cars" have the highest fatality rate per mile driven. For instance, a person driving 12,000 miles per year for 55 years would have a 1% chance of being involved in a fatal accident. This is twice the fatality rate of the safest vehicle class, a "large car". According to the data in this report, the number of fatal crashes per mile is only weakly correlated with the vehicle weight, having a correlation coefficient of just (-0.45). A stronger correlation is seen with the vehicle size within its class; for example, "large" cars, pickups and SUVs, have lower fatality rates than "small" cars, pickups and SUVs. This is the case in 7 of the 10 classes, with the exception of mid-size vehicles, where minivans and mid-size cars are among the safest classes, while mid-size SUVs are the second most fatal after very small cars. Even though heavier vehicles sometimes are statistically safer, it is not necessarily the extra weight that causes them to be safer. The NHTSA report states: "Heavier vehicles have historically done a better job cushioning their occupants in crashes. Their longer hoods and extra space in the occupant compartment provide an opportunity for a more gradual deceleration of the vehicle, and of the occupant within the vehicle... While it is conceivable that light vehicles could be built with similarly long hoods and mild deceleration pulses, it would probably require major changes in materials and design and/or taking weight out of their engines, accessories, etc."[15] Air cars may use low rolling resistance tires, which typically offer less grip than normal tires.[16][17] In addition, the weight (and price) of safety systems such as airbags, ABS and ESC may discourage manufacturers from including them. Developers and manufacturersVarious companies are investing in the research, development and deployment of Compressed air cars. Overoptimistic reports of impending production date back to at least May 1999. For instance, the MDI Air Car made its public debut in South Africa in 2002,[18] and was predicted to be in production "within six months" in January 2004.[19] As of January 2009, the air car never went into production in South Africa. Most of the cars under development also rely on using similar technology to low-energy vehicles in order to increase the range and performance of their cars.{{clarify|date=April 2014|reason=After Articles for deletion/Low-energy vehicle there is no way to tell what low-energy vehicle technology is.}} MDI{{Main|Motor Development International}}MDI has proposed a range of vehicles made up of AIRPod, OneFlowAir, CityFlowAir, MiniFlowAir and MultiFlowAir.[20] One of the main innovations of this company is its implementation of its "active chamber", which is a compartment which heats the air (through the use of a fuel) in order to double the energy output.[21] This 'innovation' was first used in torpedoes in 1904. Tata Motors{{As of|2009|1}} Tata Motors of India had planned to launch a car with an MDI compressed air engine in 2011.[22][23] In December 2009 Tata's vice president of engineering systems confirmed that the limited range and low engine temperatures were causing problems.Tata Motors announced in May 2012[24] that they have assessed the design passing phase 1, the "proof of the technical concept" towards full production for the Indian market. Tata has moved onto phase 2, "completing detailed development of the compressed air engine into specific vehicle and stationary applications".[25] In February 2017 Dr. Tim Leverton, president and head at Advanced and Product Engineering at Tata revealed was at a point of "starting industrialisation" with the first vehicles to be available by 2020.[26] Other reports indicate Tata is also looking at reviving plans for a compressed air version of the Tata Nano,[27] which had previously been under consideration as part of their collaboration with MDI.[28] EngineairEngineair is an Australian company which has produced prototypes of a variety of prototype small vehicles using an innovative rotary air engine designed by Angelo Di Pietro. The company is seeking commercial partners to utilise its engine.[29] Peugeot/CitroënPeugeot and Citroën announced that they intended to build a car that uses compressed air as an energy source. However, the car they are designing uses a hybrid system which also uses a gasoline engine (which is used for propelling the car over 70 km/h, or when the compressed air tank has been depleted).[30][31] In January 2015, there was "Disappointing news from France: PSA Peugeot Citroen has put an indefinite hold on the development of its promising-sounding Hybrid Air powertrain, apparently because the company has been unable to find a development partner willing to split the huge costs of engineering the system." Development costs are estimated to 500 million Euro for the system, which would apparently have need to be fitted to around 500,000 cars a year to make sense. [32] The head of the project left Peugeot in 2014.[33]APUQAPUQ (Association de Promotion des Usages de la Quasiturbine) has made the APUQ Air Car, a car powered by a Quasiturbine.[34] See also{{Portal|Sustainable development}}
References1. ^Bowlin, Ben. "How to Convert Gasoline Energy to Kilowatt-hours (kWh) " {{webarchive|url=https://web.archive.org/web/20150108010330/http://www.carstuffshow.com/blog/how-to-convert-gasoline-energy-to-kilowatt-hours-kwh/ |date=2015-01-08 }}, Retrieved on 7 January 2015. 2. ^{{cite journal |doi=10.1021/ef020162b |laysummary=http://www.lbl.gov/tt/techs/lbnl2570.html |laysource=Lawrence Berkeley National Laboratory |title=Carbon Dioxide as Cushion Gas for Natural Gas Storage |year=2003 |last1=Oldenburg |first1=Curtis M. |journal=Energy & Fuels |volume=17 |pages=240}} 3. ^{{Cite journal|last=Creutzig|first=Felix|last2=Papson|first2=Andrew|last3=Schipper|first3=Lee|last4=Kammen|first4=Daniel M.|date=2009-01-01|title=Economic and environmental evaluation of compressed-air cars|url=http://iopscience.iop.org/article/10.1088/1748-9326/4/4/044011/pdf|journal=Environmental Research Letters|language=en|volume=4|issue=4|pages=044011|doi=10.1088/1748-9326/4/4/044011|issn=1748-9326}} 4. ^1 {{cite news |date=October 4, 2004 |title=Car runs on compressed air, but will it sell? |url=http://www.msnbc.msn.com/id/6138972/ |agency=Associated Press |accessdate=2008-09-12}} 5. ^{{cite news |url=http://news.bioscholar.com/2011/02/air-hybrid-vehicles-could-halve-fuel-consumption-in-future.html |title=Air hybrid vehicles could halve fuel consumption in future |agency=Asian News International |date=March 20, 2011 |accessdate=2012-01-26 |archive-url=https://web.archive.org/web/20120131101212/http://news.bioscholar.com/2011/02/air-hybrid-vehicles-could-halve-fuel-consumption-in-future.html |archive-date=2012-01-31 |dead-url=yes |df= }} 6. ^{{cite web|url=http://www.seacomair.com/sca600sl.html |title=SCA650E43/HDF-SILENT SeaComAir Silent 23 cfm 11 kW Electric Motor 400 V/50 Hz or 60 Hz Three phase |deadurl=yes |archiveurl=https://web.archive.org/web/20120311212017/http://www.seacomair.com/sca600sl.html |archivedate=2012-03-11 |df= }}{{unreliable source?|date=June 2012}} 7. ^{{cite web|first1=Ulf |last1=Bossel |date=April 2, 2009 |title=Thermodynamic Analysis of Compressed Air Vehicle Propulsion |url=http://www.efcf.com/reports/E14.pdf |deadurl=yes |archiveurl=https://web.archive.org/web/20120717085501/http://www.efcf.com/reports/E14.pdf |archivedate=2012-07-17 |df= }}{{unreliable source?|date=June 2012}} 8. ^{{cite web|url=http://www.australianscience.com.au/technology/the-fuel-of-the-future/|title=The Fuel of the Future|work=Australian Science|accessdate=30 May 2015|archive-url=https://web.archive.org/web/20150407143418/http://www.australianscience.com.au/technology/the-fuel-of-the-future/|archive-date=2015-04-07|dead-url=yes|df=}} 9. ^{{cite web |url=http://www.transportation.anl.gov/pdfs/HV/300.pdf |title=Comparing Apples to Apples: Well-to-Wheel Analysis of Current ICE and Fuel Cell Vehicle Technologies, p.15 |publisher=Argonne National laboratory}} 10. ^{{cite web|author=Sebastian Braud sebb@motordeaire.com |url=http://www.theaircar.com/tests.html |title=MDI refilling stations |publisher=Web.archive.org |date=2007-03-21 |accessdate=2010-12-12 |archiveurl = https://web.archive.org/web/20070321053002/http://www.theaircar.com/tests.html |archivedate = 2007-03-21}} 11. ^{{cite web|title=Wind-to-Wheel Energy Assessment |url=http://www.efcf.com/reports/E18.pdf |format=PDF |author=Patrick Mazza |author2=Roel Hammerschlag |publisher=Institute for Lifecycle Environmental Assessment |accessdate=2008-09-12 |deadurl=yes |archiveurl=https://web.archive.org/web/20080911042043/http://www.efcf.com/reports/E18.pdf |archivedate=2008-09-11 |df= }} 12. ^{{cite web|url=http://www.mdi.lu/eng/affiche_eng.php?page=minicats |title=MDI Enterprises S.A |publisher=Mdi.lu |accessdate=2010-12-12}} 13. ^{{cite journal |doi=10.1088/1748-9326/4/4/044011 |title=Economic and environmental evaluation of compressed-air cars |year=2009 |last1=Creutzig |first1=Felix |last2=Papson |first2=Andrew |last3=Schipper |first3=Lee |last4=Kammen |first4=Daniel M |journal=Environmental Research Letters |volume=4 |issue=4 |pages=044011}} 14. ^{{cite news |first=A. |last=Pawlowski |url=http://www.cnn.com/2008/TECH/08/08/air.car/index.html |title=106 mpg 'air car' creates buzz, questions |publisher=CNN |date=August 8, 2008 |accessdate=2009-04-25}} 15. ^{{cite web |title=Vehicle Weight, Fatality Risk and Crash Compatibility of Model Year 1991-99 Passenger Cars and Light Trucks Report |date=October 2003|url=http://www.nhtsa.dot.gov/cars/rules/regrev/evaluate/pdf/809662.pdf |format=PDF |publisher=United States Department of Transportation |first=Charles J. |last=Kahane |accessdate=2008-09-12}} 16. ^{{cite web|title=Low-rolling-resistance tires|url=http://www.consumerreports.org/cro/cars/tires-auto-parts/tires/low-rolling-resistance-tires-8-06/overview/0608_low-rolling-resistance-tires_ov.htm|publisher=Consumer Reports|accessdate=2008-09-12}} 17. ^{{cite web|title=Planned EU Requirements for Tires Would Reduce Road Traffic Safety |url=http://www.conti-online.com/generator/www/com/en/continental/portal/themes/press_services/press_releases/safety/pr_2007_11_12_eu_vorgaben_en.html|publisher=Continental AG|accessdate=2008-09-12}} {{Dead link|date=September 2010|bot=H3llBot}} 18. ^{{cite web| title=How Air-Powered Cars Will Work | author=Kevin Bonsor | publisher=HowStuffWorks |date=2005-10-25 | accessdate=2006-05-25 | url=http://auto.howstuffworks.com/air-car.htm/printable}} 19. ^{{cite news | title=Gone with the wind | author=Robyn Curnow | publisher=The Sunday Times (UK) |date=2004-01-11 | accessdate=2006-05-25 | url=http://www.timesonline.co.uk/printFriendly/0,,1-120-957436-120,00.html | location=London}} 20. ^Learn everything about the compressed air cars! {{Webarchive|url=https://web.archive.org/web/20130520152900/http://aircars.tk/ |date=2013-05-20 }}. 21. ^{{cite web |url=http://www.thefuture.net.nz/mdi_tech.htm |title=MDI's active chamber |publisher=Thefuture.net.nz |accessdate=2010-12-12 |deadurl=yes |archiveurl=https://web.archive.org/web/20110507151344/http://www.thefuture.net.nz/mdi_tech.htm |archivedate=2011-05-07 |df= }} 22. ^{{cite web |title=Tata Air Car to drive in by 2011 |publisher=Popular Mechanics |url=http://www.dancewithshadows.com/autoindia/tata-air-car-to-drive-in-by-2011/ |deadurl=yes |archiveurl=https://web.archive.org/web/20100210193936/http://www.dancewithshadows.com/autoindia/tata-air-car-to-drive-in-by-2011/ |archivedate=2010-02-10 |df= }} 23. ^{{cite press release|title=An engine which uses air as fuel: Tata Motors and technology inventor, MDI of France, sign agreement |publisher=Tata Motors |date=February 5, 2007 |url=http://tatamotors.com/media/press-releases.php?id=281 |accessdate=June 14, 2012 |deadurl=yes |archiveurl=https://web.archive.org/web/20120314135550/http://www.tatamotors.com/media/press-releases.php?id=281 |archivedate=March 14, 2012 |df= }} 24. ^{{cite press release|title=MDI's air engine technology tested on Tata Motors vehicles |publisher=Tata Motors |date=May 7, 2012 |url=http://www.tatamotors.com/media/press-releases.php?id=750 |accessdate=June 14, 2012 |deadurl=yes |archiveurl=https://web.archive.org/web/20130509064540/http://www.tatamotors.com/media/press-releases.php?id=750 |archivedate=May 9, 2013 |df= }} 25. ^Tata Motors enters second phase of air-car development Gizmag.com, 2012-05-07{{unreliable source?|date=June 2012}} 26. ^{{cite web|title=Tata Motors' air-powered car project still on, to be launch ready in 3 years|url=http://www.autocarpro.in/news-national/tata-motors-air-powered-car-project-launch-23659|website=Auto Car Professional|accessdate=24 August 2017}} 27. ^{{cite news|title=Tata Nano could spawn electric, hybrid & air-powered variants – Report|url=http://indianautosblog.com/2017/01/tata-nano-could-spawn-electric-hybrid-air-variants-256298|accessdate=23 August 2017|publisher=Indian Autos Blog|date=Jan 25, 2017}} 28. ^{{cite news|title=Nano was to run on air, battery but Ratan Tata couldn’t implement plans|url=http://www.hindustantimes.com/business-news/ratan-tata-s-plan-to-turn-nano-around-wanted-car-to-run-on-air-battery/story-q7LIMmTS5eHCORFTvNhE1L.html|accessdate=23 August 2017|publisher=Hindustan Times|date=Oct 28, 2016}} 29. ^{{cite web|title=The motorbike that runs on air|url=http://smh.drive.com.au/motor-news/the-motorbike-that-runs-on-air-20111103-1mwq2.html|author=Matt Campbell|date=November 3, 2011|publisher=Sydney Morning Herald|accessdate=2011-11-07|deadurl=yes|archiveurl=https://web.archive.org/web/20111105173816/http://smh.drive.com.au/motor-news/the-motorbike-that-runs-on-air-20111103-1mwq2.html|archivedate=November 5, 2011|df=}} 30. ^{{cite web|url=http://gas2.org/2013/02/18/compressed-air-hybrid-car-developed/ |title=Compressed-Air Hybrid Car Developed |publisher=Gas2.org |date=2013-02-18 |accessdate=2013-09-08}} 31. ^{{cite web|url=http://inhabitat.com/peugeot-announces-plans-to-release-a-hybrid-car-that-runs-on-compressed-air-by-2016/|title=Peugeot Announces Plans to Release a Hybrid Car That Runs on Compressed Air by 2016|author=Marc Carter|publisher=|accessdate=30 May 2015}} 32. ^{{Cite news|url=https://blog.caranddriver.com/deflated-peugeot-citroen-shelves-its-air-hybrid-technology/|title=Deflated: Peugeot Citroen Shelves Its Air Hybrid Technology|last=Duff|first=Mike|date=January 26, 2015|work=Car and Driver|access-date=2018-10-29|language=en}} 33. ^{{Cite web|url=https://www.lesechos.fr/11/01/2015/lesechos.fr/0204071426759_psa---la-revolution-de-l-hybrid-air-n-aura-pas-lieu.htm|title=PSA : la révolution de l’Hybrid Air n’aura pas lieu|last=Fansilber|first=Maxime Amiot Denis|date=November 1, 2015|website=Les Echos|language=fr|archive-url=|archive-date=|dead-url=|access-date=2018-10-29}} 34. ^{{cite web|url=http://www.apuq.com |title=Association de Promotion des Usages de la Quasiturbine |publisher=APUQ |accessdate=2012-01-26}}{{unreliable source?|date=June 2012}} External links{{Commons category|Compressed-air-powered automobiles}}
2 : Automotive technologies|Compressed air power |
