The Armstrong oscillator^[1] (also known as the Meissner oscillator^[2]) is an electronic oscillator circuit which uses an inductor and capacitor to generate an oscillation. It is the earliest oscillator circuit, invented by US engineer Edwin Armstrong in 1912 and independently by Austrian engineer Alexander Meissner in 1913, and was used in the first vacuum tube radio transmitters. It is sometimes called a tickler oscillator because its distinguishing feature is that the feedback signal needed to produce oscillations is magnetically coupled into the tank inductor in the input circuit by a "tickler coil" (L2, right) in the output circuit. Assuming the coupling is weak, but sufficient to sustain oscillation, the oscillation frequency f is determined primarily by the tank circuit (L1 and C in the figure on the right) and is approximately given by

This circuit was widely used in the regenerative radio receiver, popular until the 1940s. In that application, the input radio frequency signal from the antenna is magnetically coupled into the tank circuit by an additional winding, and the feedback is reduced with an adjustable gain control in the feedback loop, so the circuit is just short of oscillation. The result is a narrow-band radio-frequency filter and amplifier. The non-linear characteristic of the transistor or tube also demodulated the RF signal to produce the audio signal.

The circuit diagram shown is a modern implementation, using a field-effect transistor as the amplifying element. Armstrong's original design used a triode vacuum tube.

Note that in the Meissner variant, the LC resonant (tank) circuit is exchanged with the feedback coil, i.e. in the output path (vacuum tube plate, field effect transistor drain, or bipolar transistor collector) of the amplifier (e.g. Grebennikov, Fig. 2.8).^[3] Many publications, however, embrace both variants with either name. Apparently, the English speakers using Armstrong, and the German speakers Meißner.

See also

Footnotes

1. ^{{Citation |inventor-first=Edwin H. |inventor-last=Armstrong |inventorlink=Edwin H. Armstrong |title=Wireless receiving system |country-code=US |patent-number=1113149 |publication-date=19 October 1913 |issue-date=6 October 1914}}. In Figure 1, a tapped inductor ("auto-transformer") provides the feedback; in Figure 6, a transformer provides the feedback.
2. ^{{Citation |inventor-first=Alexander |inventor-last=Meissner |inventorlink=Alexander Meissner |title=Einrichtung zur Erzeugung elektrischer Schwingungen |trans-title=Equipment for production of electrical oscillations |country-code=DE |patent-number=291604 |publication-date=April 10, 1913 |issue-date=June 23, 1919 |language=German }}, [Equipment for production of electrical oscillations] in German. The patent does not mention Meissner; the patent was issued to Gesellschaft für Drahtlose Telegraphie mbH [Corporation for Wireless Telegraphy].
3. ^{{Citation |first=A. |last=Grebennikov |title=RF and Microwave Transistor Oscillator Design |publisher=Wiley |year=2007 |isbn=978-0-470-02535-2 |doi= }}
