The Crystal Mover is an automated people mover (APM) system for airport and light rail applications manufactured by Mitsubishi Heavy Industries in Mihara, Japan. The Crystal Mover is based on the Japanese APM standard, used in six Japanese automated guideway transit systems including the Yurikamome and the Rokko Island Line.[1]

Public transport

Singapore

In Singapore, Crystal Movers operate between the Sengkang LRT Line and the Punggol LRT Line, operated by SBS Transit. These cars have been operating since 2003 on the Sengkang LRT and on the Punggol LRT since its operation in 2005. There is a fleet of 41 cars of Mitsubishi Heavy Industries Crystal Mover C810 in total for the two LRT lines.[2][3] An additional order was placed for 16 more cars (Contract 810A) with identical specifications to increase capacity on both LRT lines, and had been fully delivered as of 2016.[2]

Macau

On 31 December 2010, Macau placed a MOP 4.688 billion order for Crystal Movers for the Macau Light Transit System, which is expected to start revenue operation in 2019.[4]

Airport connections

Crystal Movers are currently in operation in the following airports:

  • AeroTrain, Washington Dulles International Airport, United States
  • ATL Skytrain, Hartsfield-Jackson Atlanta International Airport, United States
  • Changi Airport Skytrain, Singapore Changi Airport, Singapore
  • HKIA Automated People Mover, Hong Kong International Airport, Hong Kong
  • MIA Mover and Skytrain, Miami International Airport, United States
  • Shuttle Train, Incheon International Airport, South Korea
  • Terminal 3 APM, Dubai International Airport Terminal 3, UAE
  • Orlando International Airport People Movers, Orlando International Airport (Gates 30-59 only, with replacement of the existing CX100 shuttles for gates 1-29 in progress.)[5]
  • Tampa International Airport SkyConnect, United States

Specifications

  • Configuration: Single-car or Double-car
  • Capacity (passengers): 105 (including 18 seats) or 210 (including 36 seats)
  • Vehicle mass (t): 14.9/vehicle
  • Vehicle dimensions (mm): 11 840 (length) × 2 690 (width) × 3 615 (height)
  • Guide system: Side guide two-axis four-wheel steering system
  • Electric system: 750 Volts Direct Current
  • Gauge (mm): Gauge, 1 850; guide rail span, 3 200
  • Maximum speed
    • Vehicle performance: 80 km/h
    • Operation: 70 km/h
  • Acceleration: 1.0 m/s² (3.6 km/h/s)
  • Deceleration
    • Maximum service: 1.0 m/s² (3.6 km/h/s)
    • Emergency: 1.3 m/s² (4.7 km/h/s)
  • Car body structure: Aluminum alloy welded structure
  • Traction motor: Three-phase induction motor, continuous rating 80 kW × 2 units
  • Propulsion control system: VVVF inverter vector control (individual control of each axis)

(with variable load control and regenerative brake)

  • Brake system: Electric command pneumatic brake with regenerative brake

(with stand-by brake and parking brake)

(with variable load control and wheel slide prevention control)

See also

{{commons|Mitsubishi Heavy Industries Crystal Mover}}{{Div col}}
  • Bombardier Innovia APM 100, a popular competing airport APM
  • Bombardier Innovia APM 200, a newer competing airport APM and direct competitor to the Crystal Mover
  • Light Rail Transit (Singapore)
  • Véhicule Automatique Léger
  • Mitsubishi Heavy Industries Crystal Mover C810
  • Mitsubishi Heavy Industries Crystal Mover C810A
  • Mitsubishi Heavy Industries Crystal Mover (Changi Airport Skytrain)
  • Roll way
{{div col end}}
