In numerical analysis and functional analysis, a discrete wavelet transform (DWT) is any wavelet transform for which the wavelets are discretely sampled. As with other wavelet transforms, a key advantage it has over Fourier transforms is temporal resolution: it captures both frequency and location information (location in time).

Examples

Haar wavelets

The first DWT was invented by Hungarian mathematician Alfréd Haar. For an input represented by a list of

numbers, the Haar wavelet transform may be considered to pair up input values, storing the difference and passing the sum. This process is repeated recursively, pairing up the sums to prove the next scale, which leads to

differences and a final sum.

Daubechies wavelets

The most commonly used set of discrete wavelet transforms was formulated by the Belgian mathematician Ingrid Daubechies in 1988. This formulation is based on the use of recurrence relations to generate progressively finer discrete samplings of an implicit mother wavelet function; each resolution is twice that of the previous scale. In her seminal paper, Daubechies derives a family of wavelets, the first of which is the Haar wavelet. Interest in this field has exploded since then, and many variations of Daubechies' original wavelets were developed.^[1]^[2]

The dual-tree complex wavelet transform (DℂWT)

The dual-tree complex wavelet transform (ℂWT) is a relatively recent enhancement to the discrete wavelet transform (DWT), with important additional properties: It is nearly shift invariant and directionally selective in two and higher dimensions. It achieves this with a redundancy factor of only

substantially lower than the undecimated DWT. The multidimensional (M-D) dual-tree ℂWT is nonseparable but is based on a computationally efficient, separable filter bank (FB).^[3]

Others

Other forms of discrete wavelet transform include the non- or undecimated wavelet transform (where downsampling is omitted), the Newland transform (where an orthonormal basis of wavelets is formed from appropriately constructed top-hat filters in frequency space). Wavelet packet transforms are also related to the discrete wavelet transform. Complex wavelet transform is another form.

Properties

The Haar DWT illustrates the desirable properties of wavelets in general. First, it can be performed in

operations; second, it captures not only a notion of the frequency content of the input, by examining it at different scales, but also temporal content, i.e. the times at which these frequencies occur. Combined, these two properties make the Fast wavelet transform (FWT) an alternative to the conventional fast Fourier transform (FFT).

Time issues

Due to the rate-change operators in the filter bank, the discrete WT is not time-invariant but actually very sensitive to the alignment of the signal in time. To address the time-varying problem of wavelet transforms, Mallat and Zhong proposed a new algorithm for wavelet representation of a signal, which is invariant to time shifts.^[4] According to this algorithm, which is called a TI-DWT, only the scale parameter is sampled along the dyadic sequence 2^j (j∈Z) and the wavelet transform is calculated for each point in time.^[5]^[6]

Applications

The discrete wavelet transform has a huge number of applications in science, engineering, mathematics and computer science. Most notably, it is used for signal coding, to represent a discrete signal in a more redundant form, often as a preconditioning for data compression. Practical applications can also be found in signal processing of accelerations for gait analysis,^[7] image processing,^[8] in digital communications and many others.^[9]

It is shown that discrete wavelet transform (discrete in scale and shift, and continuous in time) is successfully implemented as analog filter bank in biomedical signal processing for design of low-power pacemakers and also in ultra-wideband (UWB) wireless communications.^[12]

Example in Image Processing

Wavelets are often used to denoise two dimensional signals, such as images. The following example provides three steps to remove unwanted white Gaussian noise from the noisy image shown. Matlab was used to import and filter the image.

The first step is to choose a wavelet type, and a level N of decomposition. In this case biorthogonal 3.5 wavelets were chosen with a level N of 10. Biorthogonal wavelets are commonly used in image processing to detect and filter white Gaussian noise,^[13] due to their high contrast of neighboring pixel intensity values. Using this wavelets a wavelet transformation is performed on the two dimensional image.

Following the decomposition of the image file, the next step is to determine threshold values for each level from 1 to N. Birgé-Massart strategy^[14] is a fairly common method for selecting these thresholds. Using this process individual thresholds are made for N = 10 levels. Applying these thresholds are the majority of the actual filtering of the signal.

The final step is to reconstruct the image from the modified levels. This is accomplished using an inverse wavelet transform. The resulting image, with white Gaussian noise removed is shown below the original image. When filtering any form of data it is important to quantify the signal-to-noise-ratio of the result.^[15] In this case, the SNR of the noisy image in comparison to the original was 30.4958%, and the SNR of the denoised image is 32.5525%. The resulting improvement of the wavelet filtering is a SNR gain of 2.0567%.^[16]

It is important to note that choosing other wavelets, levels, and thresholding strategies can result in different types of filtering. In this example, white Gaussian noise was chosen to be removed. Although, with different thresholding, it could just as easily have been amplified.

Comparison with Fourier transform

To illustrate the differences and similarities between the discrete wavelet transform with the discrete Fourier transform, consider the DWT and DFT of the following sequence: (1,0,0,0), a unit impulse.

while the DWT with Haar wavelets for length 4 data has orthogonal basis in the rows of:

(To simplify notation, whole numbers are used, so the bases are orthogonal but not orthonormal.)

The DWT demonstrates the localization: the (1,1,1,1) term gives the average signal value, the (1,1,–1,–1) places the signal in the left side of the domain, and the

(1,–1,0,0) places it at the left side of the left side, and truncating at any stage yields a downsampled version of the signal:

The DFT, by contrast, expresses the sequence by the interference of waves of various frequencies – thus truncating the series yields a low-pass filtered version of the series:

Notably, the middle approximation (2-term) differs. From the frequency domain perspective, this is a better approximation, but from the time domain perspective it has drawbacks – it exhibits undershoot – one of the values is negative, though the original series is non-negative everywhere – and ringing, where the right side is non-zero, unlike in the wavelet transform. On the other hand, the Fourier approximation correctly shows a peak, and all points are within

of their correct value, though all points have error. The wavelet approximation, by contrast, places a peak on the left half, but has no peak at the first point, and while it is exactly correct for half the values (reflecting location), it has an error of

for the other values.

This illustrates the kinds of trade-offs between these transforms, and how in some respects the DWT provides preferable behavior, particularly for the modeling of transients.

Definition

One level of the transform

The DWT of a signal

is calculated by passing it through a series of filters. First the samples are passed through a low pass filter with impulse response

resulting in a convolution of the two:

The signal is also decomposed simultaneously using a high-pass filter

. The outputs giving the detail coefficients (from the high-pass filter) and approximation coefficients (from the low-pass). It is important that the two filters are related to each other and they are known as a quadrature mirror filter.

However, since half the frequencies of the signal have now been removed, half the samples can be discarded according to Nyquist’s rule. The filter output of the low-pass filter

in the diagram above is then subsampled by 2 and further processed by passing it again through a new low- pass filter

and a high- pass filter

with half the cut-off frequency of the previous one,i.e.:

This decomposition has halved the time resolution since only half of each filter output characterises the signal. However, each output has half the frequency band of the input, so the frequency resolution has been doubled.

However computing a complete convolution

with subsequent downsampling would waste computation time.

The Lifting scheme is an optimization where these two computations are interleaved.

Cascading and filter banks

This decomposition is repeated to further increase the frequency resolution and the approximation coefficients decomposed with high and low pass filters and then down-sampled. This is represented as a binary tree with nodes representing a sub-space with a different time-frequency localisation. The tree is known as a filter bank.

At each level in the above diagram the signal is decomposed into low and high frequencies. Due to the decomposition process the input signal must be a multiple of

where

is the number of levels.

For example a signal with 32 samples, frequency range 0 to

and 3 levels of decomposition, 4 output scales are produced:

Relationship to the mother wavelet

The filterbank implementation of wavelets can be interpreted as computing the wavelet coefficients of a discrete set of child wavelets for a given mother wavelet

. In the case of the discrete wavelet transform, the mother wavelet is shifted and scaled by powers of two

where

is the scale parameter and

is the shift parameter, both which are integers.

Recall that the wavelet coefficient

of a signal

is the projection of

onto a wavelet, and let

be a signal of length

. In the case of a child wavelet in the discrete family above,

Now fix

at a particular scale, so that

is a function of

only. In light of the above equation,

can be viewed as a convolution of

with a dilated, reflected, and normalized version of the mother wavelet,

, sampled at the points

. But this is precisely what the detail coefficients give at level

of the discrete wavelet transform. Therefore, for an appropriate choice of

and

, the detail coefficients of the filter bank correspond exactly to a wavelet coefficient of a discrete set of child wavelets for a given mother wavelet

As an example, consider the discrete Haar wavelet, whose mother wavelet is

. Then the dilated, reflected, and normalized version of this wavelet is

, which is, indeed, the highpass decomposition filter for the discrete Haar wavelet transform.

Time complexity

The filterbank implementation of the Discrete Wavelet Transform takes only O(N) in certain cases, as compared to O(N log N) for the fast Fourier transform.

Note that if

and

are both a constant length (i.e. their length is independent of N), then

and

each take O(N) time. The wavelet filterbank does each of these two O(N) convolutions, then splits the signal into two branches of size N/2. But it only recursively splits the upper branch convolved with

(as contrasted with the FFT, which recursively splits both the upper branch and the lower branch). This leads to the following recurrence relation

which leads to an O(N) time for the entire operation, as can be shown by a geometric series expansion of the above relation.

As an example, the discrete Haar wavelet transform is linear, since in that case

and

are constant length 2.

Other transforms

The Adam7 algorithm, used for interlacing in the Portable Network Graphics (PNG) format, is a multiscale model of the data

Unlike the DWT, it has a specific scale – it starts from an 8×8 block, and it downsamples the image, rather than decimating (low-pass filtering, then downsampling). It thus offers worse frequency behavior, showing artifacts (pixelation) at the early stages, in return for simpler implementation.

Code example

Complete Java code for a 1-D and 2-D DWT using Haar, Daubechies, Coiflet, and Legendre wavelets is available from the open source project: [https://github.com/cscheiblich/JWave JWave].

Furthermore, a fast lifting implementation of the discrete biorthogonal CDF 9/7 wavelet transform in C, used in the JPEG 2000 image compression standard can be found [https://web.archive.org/web/20120305164605/http://www.embl.de/~gpau/misc/dwt97.c here] (archived 5 March 2012).

Example of above code

This figure shows an example of applying the above code to compute the Haar wavelet coefficients on a sound waveform. This example highlights two key properties of the wavelet transform:
